KWVE35WL Schaeffler INA Ball Carriage Linear Bearing Runner Block
KWVE35WL Schaeffler INA Ball Carriage Linear Bearing Runner Block
Regular price
$350.00 USD
Regular price
Sale price
$350.00 USD
Unit price
per
Couldn't load pickup availability
KWVE35-WL
INA Recirculating ball bearing carriage KWVE35WL
Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly
Main Dimensions & Performance Data
| H |
50 mm
|
height system |
| B |
162 mm
|
width carriage |
| L |
140.2 mm
|
overall length carriage |
| C |
47,500 N
|
dynamic load rating 1 |
| C0 |
100,000 N
|
static load rating 1 |
| M0x |
5,550 Nm
|
static moment rating about X axis |
| M0y |
1,890 Nm
|
static moment rating about Y axis |
| M0z |
1,890 Nm
|
static moment rating about Z axis |
| ≈m |
4.11 kg
|
Weight |
