INA
KWVE35BHL Schaeffler INA Ball Carriage Linear Bearing Runner Block
KWVE35BHL Schaeffler INA Ball Carriage Linear Bearing Runner Block
Regular price
$155.00 USD
Regular price
Sale price
$155.00 USD
Unit price
per
Couldn't load pickup availability
KWVE35-B-HL
INA Recirculating ball bearing carriage KWVE35BHL
Carriages KWVE..-B-HL, high, narrow, long carriage, four-row
Main Dimensions & Performance Data
| H |
55 mm
|
height system |
| B |
70 mm
|
width carriage |
| L |
145 mm
|
overall length carriage |
| C |
47,500 N
|
dynamic load rating 1 |
| C0 |
100,000 N
|
static load rating 1 |
| M0x |
2,625 Nm
|
static moment rating about X axis |
| M0y |
1,890 Nm
|
static moment rating about Y axis |
| M0z |
1,890 Nm
|
static moment rating about Z axis |
| ≈m |
2.4 kg
|
Weight |
