INA
KWVE30W Schaeffler INA Ball Carriage Linear Bearing Runner Block
KWVE30W Schaeffler INA Ball Carriage Linear Bearing Runner Block
Regular price
$260.00 USD
Regular price
Sale price
$260.00 USD
Unit price
per
Couldn't load pickup availability
INA Recirculating ball bearing carriage KWVE30W
Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly
Main Dimensions & Performance Data
| H |
42 mm
|
height system |
| B |
142 mm
|
width carriage |
| L |
97.5 mm
|
overall length carriage |
| C |
27,500 N
|
dynamic load rating 1 |
| C0 |
55,000 N
|
static load rating 1 |
| M0x |
2,660 Nm
|
static moment rating about X axis |
| M0y |
700 Nm
|
static moment rating about Y axis |
| M0z |
700 Nm
|
static moment rating about Z axis |
| ≈m |
1.95 kg
|
Weight |
