INA
KWVE30BEC Schaeffler INA Ball Carriage Linear Bearing Runner Block
KWVE30BEC Schaeffler INA Ball Carriage Linear Bearing Runner Block
Regular price
$135.00 USD
Regular price
Sale price
$135.00 USD
Unit price
per
Couldn't load pickup availability
KWVE30-B-EC
INA Recirculating ball bearing carriage KWVE30BEC
Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row
Main Dimensions & Performance Data
| H |
42 mm
|
height system |
| B |
90 mm
|
width carriage |
| L |
69 mm
|
overall length carriage |
| C |
18,700 N
|
dynamic load rating 1 |
| C0 |
31,500 N
|
static load rating 1 |
| M0x |
554 Nm
|
static moment rating about X axis |
| M0y |
248 Nm
|
static moment rating about Y axis |
| M0z |
248 Nm
|
static moment rating about Z axis |
| ≈m |
0.75 kg
|
Weight |
