INA
KWVE25BN Schaeffler INA Ball Carriage Linear Bearing Runner Block
KWVE25BN Schaeffler INA Ball Carriage Linear Bearing Runner Block
Regular price
$90.00 USD
Regular price
Sale price
$90.00 USD
Unit price
per
Couldn't load pickup availability
KWVE25-B-N
INA Recirculating ball bearing carriage KWVE25BN
Carriages KWVE..-B-N, low carriage, four-row
Main Dimensions & Performance Data
| H |
31 mm
|
height system |
| B |
70 mm
|
width carriage |
| L |
83.3 mm
|
overall length carriage |
| C |
17,900 N
|
dynamic load rating 1 |
| C0 |
37,000 N
|
static load rating 1 |
| M0x |
510 Nm
|
static moment rating about X axis |
| M0y |
395 Nm
|
static moment rating about Y axis |
| M0z |
395 Nm
|
static moment rating about Z axis |
| ≈m |
0.56 kg
|
Weight |
