KWVE15BS Schaeffler INA Ball Carriage Linear Bearing Runner Block

KWVE15BS Schaeffler INA Ball Carriage Linear Bearing Runner Block

Regular price $70.00 USD
Regular price Sale price $70.00 USD
Sale Sold out

KWVE15-B-S

INA Recirculating ball bearing carriage KWVE15BS

Carriages KWVE..-B-S, narrow carriage, four-row

0001635B

Main Dimensions & Performance Data
H
24 mm
height system
B
34 mm
width carriage
L
61.2 mm
overall length carriage
C
7,200 N
dynamic load rating 1
C0
14,500 N
static load rating 1
M0x
150 Nm
static moment rating about X axis
M0y
100 Nm
static moment rating about Y axis
M0z
100 Nm
static moment rating about Z axis
≈m
0.16 kg
Weight
